Switch Supermicro SSE-X24S Maximize

Switch Supermicro SSE-X24S

• 24x ten Gigabit Ethernet ports
• Switching Capacity: 480Gbps
• Wire-speed Layer 3 Routing
• 1:1 Non-blocking connectivity
• Link Aggregation and Jumbo Frame Support
• 1U form factor for flexible installation
• CLI and Web GUI Management Interfaces

Plus de détails

Layer 3 10G Ethernet Switch (Stand-alone)

High-Performance, High Density, Advanced Switching Capabilities for Meeting 10-Gigabit Ethernet Networking Requirements scaling from Small Business to the Enterprise

SSE-X24S Layer 3 Ethernet Switch offers twenty-four 10-Gigabit Ethernet ports allowing connectivity to 10GE routers, servers, backbones, and data centers. The 1U form factor gives users the ability to optimize deployment in wiring closet or top-of-rack environments. A comprehensive routing and protocol software suite ensures optimal performance in even the most demanding enterprise-class networking environments. It is ideal for organizations with growing and consolidated data centers.
Compliance
RoHS
RoHS 6/6
Download
User's GuideSee Appendix A of the SuperBlade Network Modules User's Manual for Installation Instructions [ Download ]
Specifications - Features
  • Dimensions:
    - 17.3" W x 15.2" D x 1.7" H
    (440mm W x 386mm D x 43mm H)
  • Switching Features:
    - Link Aggregation - 8 groups with 8 members per group
    - LACP Support
    - Link Layer Discovery Protocol (802.1AB)
    - Jumbo Frame Support
    - Port Mirroring - N to 1. Tx & Rx Configurable
  • Routing Features:
    - Static Routing, RIP v1/v2, RIPng, OSPF v1/v2/v3 & BGP
    - IPv4 and IPv6 Routing
    - VRRP (Virtual Router Redundancy Protocol)
    - DVMRP (Distance Vector Multicast Routing Protocol)

Specification
  • Port Attributes:
    - 24 Ten Gigabit Ethernet ports - SFP+ Connectors
    - Out-of-band RS-232 Management port
  • Performance:
    - Switching capacity: 480 Gbps
  • Availability:
    - Spanning Tree (802.1D)
    - Rapid Spanning Tree (802.1w)
    - Multiple Spanning Trees (802.1s)
    - Virtual Redundant Routing Protocol (VRRP)
  • VLAN:
    - 802.1Q tagging, port and protocol based
    - 4K VLANs
    - Dynamic VLAN Support (GVRP)
  • Quality of Service and DiffServ:
    - 8 priority queues per port
    - Adjusted WRR and Strict Priority Scheduling
    - Layer 2 / 3 / 4 Prioritization
    - Marking
    - Metering / Rate limiting
  • Multicast:
    - IGMP Snooping v1/ v2/ v3
    - IGMP v1/ v2/ v3
    - PIM SM, PIM DM
    - PIM SMv6
  • Security:
    - 802.1x Port Based Authentication
    - Switch access password protection
    - Layer 2 / 3 / 4 Access control Lists
    - RADIUS and TACACS+ Authentication
    - SSH / SSL Encryption
  • Management:
    - Web-based management interface
    - HTTP, HTTPS
    - Industry standard CLI with telnet, SSH or
    local management port
    - Scripting capability
    - Command completion
    - Context sensitive
    - Multiple levels of user privileges (CLI and Web UI)
    - SNMP v1/v2/v3
    - Four RMON Groups - (1, 2, 3 and 9)
    - Logging - syslog
    - Dual firmware images
    - Configuration file - upload / download
  • Dimensions:
    - 17.3"W x 15.2"D x 1.7"H
    (440mmW – 386mmD x 43mmH)
  • Power:
    - Dual 300W Power Supplies
    - Redundant & Hot-swappable
  • Operating Temperature:
    - 0° to 40°
Compatible Servers
  • n/a
