Carte Réseau Supermicro AOC-EXPX9502FXSR Maximize

Carte Réseau Supermicro AOC-EXPX9502FXSR

• Standard low-profile Dual-Port 10Gb Ethernet card
• Interface: PCI-E x8
• Port: 2 XFP ports
• Speed: 10 Gigabit/port
• Controller: Intel® 82598EB

Plus de détails

Add-on Card

The Most Power Efficient 10 Gigabit Ethernet Controller with Dual XFP Connectors

The AOC-EXPX9502FXSR is a 2-port 10 Gigabit Ethernet card with dual XFP optical output connectors designed to meet the throughput and latency requirements of bandwidth hungry applications, while offering a very low power envelope for energy efficiency. This is the ideal choice for multi-core processors and optimized for virtualization and at the same time it satisfies the need for storage over Ethernet by supporting iSCSI acceleration and providing advanced features for unified storage connectivity.

To order, contact your distributor. This product is only available through Supermicro.
Compliance
RoHS
RoHS 6/6
  • RoHS Compliant 6/6, Pb Free
Downloads
User's GuideDownload ]
DriverFTP Site ]
Driver CDFTP Site ]
Data SheetDownload ]
Compatible Motherboards and Servers
Motherboards
All motherboards with minimum PCI-E x8 slot
Servers
All servers with low-profile or full-height PCI-E expansion slot
Compatible Cable
Fiber Optic SR (850nm) cable up to 300m (Not Included)

Highlights
  • PCI Express 2.0 (2.5GT/s)
  • Low-profile
  • Intel® I/O Acceleration Technology (I/OAT)
  • Load Balancing on Multiple CPUs
  • VMDq for Virtualized Environment
  • Low-latency Interrupts
  • 10GBASE-SR on multi-mode fiber
  • Support up to 300m Fiber Cable
  • iSCSI Remote Boot
  • Intel® PROSet Utility for Windows Device Manager
Specification
  • Intel® 82598EB dual-port 10GbE controller
  • Two XFP connectors
  • PCI-E x8
  • Low-profile standard form factor
  • Intel® I/OAT to improve CPU utilization
  • MSI-X support to minimize the overhead of interrupts and allow load balancing of interrupt handling between different CPU/cores
  • Low-latency interrupts
  • Optimized queues: 32 Transmit (Tx) and 64 Receive (Rx) per port
  • VMDq for virtualized environments
  • Advanced packet filtering (per port)
  • Direct Cache Access (DCA)
  • PXE 2.0 enabled through boot read-only memory (ROM)
  • iSCSI remote boot
  • Supported fiber cable length up to 300 meters
  • Supported OS: Windows®, Linux, VMWare
  • Typical power consumption: 14W (1.17A @ 12V)
  • Storage temperature: -40°C to 70°C (-40°F to 158°F)
  • Storage humidity: 90% non-condensing relative humidity at 35°C
  • Physical dimensions: 16.74cm (6.59 in) x 6.89cm (2.71 in) (L x W)
  • Height of end brackets:
    standard - 12cm (4.725 in),
    low-profile - 7.92cm (3.12 in)
