Carte Réseau Supermicro AOC-PG-i2+ Maximize

Carte Réseau Supermicro AOC-PG-i2+

• Proprietary low-profile Dual-Port 1Gb Ethernet card
• Interface: PCI-E x8
• Port: 2 RJ45 ports
• Speed: 1 Gigabit/port
• Controller: Intel® 82576EB

Plus de détails

1GbE Server Adapter

The Smallest and Highest Performance Dual-Port Gigabit Ethernet Controller

AOC-PG-I2+ is designed to fit in 1U next generation Intel® Tylersburg-based systems. It allows users to add two additional LAN ports without sacrificing valuable space which can be used for additional, larger cards. Based on the versatile Intel® 82576EB controller the AOC-PG-i2+ produces the best performance and efficiency. As part of the VMDq ecosystem it is also the perfect card for virtualized environments. The AOC-PG-i2+ is the ideal choice for the most demanding users looking to maximize connectivity in a small form factor.

To order, contact your distributor. This product is only available through Supermicro.
Compliance / Environmental
RoHS
RoHS 6/6
  • RoHS Compliant 6/6, Pb Free
Environmental
  • Operating temperature: 0°C to 55°C
Downloads
User's GuideDownload ] (287 KB)
DriverFTP Site ]
Driver CDFTP Site ]
DatasheetDownload ]
Compatible Cable
Category-5 cable up to 100m (Not Included)

Highlights
  • PCI-E x4 2.0 (2.5GT/s)
  • Intel® I/O Acceleration Technology 2(I/O AT2)
  • Jumbo Frames support up to 9.5KB packets
  • VMDq for Virtualized Environments
  • Next-Generation VMDq
  • Low-latency interrupts
  • Direct Cache Access (DCA)
  • Intel® PROSet Utility for Teaming
Specifications
  • Intel® 82576EB dual-port Gigabit Ethernet controller
  • Dual RJ45 connectors
  • PCI-E x4 signal in PCI-E x8 connector
  • Low-profile proprietary form
    factor *
  • Intel® I/O AT to improve CPU utilization
  • MSI-X support to minimize the overhead of interrupts and allow load balancing of interrupt handling between different CPUs/cores
  • Low-latency interrupts
  • Support caches up to 64 packets descriptors per queue
  • Support for transmission and reception of packets up to 9.5KBs (Jumbo Frames)
  • IEEE 802.3 auto-negotiation
  • IEEE 802.3 compliant flow-control support
  • VMDq for virtualized environments
  • Next-Generation VMDq that provides loopback functionality to improve throughput and lower CPU utilization
  • Direct Cache Access (DCA)
  • Tx/Rx IP, TCP, and UDP checksum offloading (IPv4, IPV6) capabilities
  • Tx TCP segmentation offloading (IPv4, IPv6)
  • Intel® PROSet Utility for Windows Device Manager to support LAN teaming
  • Supported cable length is more than 100 meters
  • Supported OS: Windows®, Linux, VMWare, FreeBSD, Netware
  • Typical power consumption: 3.5W
  • Storage temperature: -40°C to 70°C (-40°F to 158°F)
  • Storage humidity: 90% non-condensing relative to humidity at 35°C
  • Physical dimensions: 9.6cm (3.78in) x 6.2cm (2.44in) (L x W)
  • Height of end bracket: low-profile - 8.0cm (3.15in)
Compatible UIO Motherboards and Servers
Motherboards
X8DTU, X8DTU-F
Servers
6016T-NT(R)F, 1026T-U(R)F, 6016T-U(R)F
Riser Card
Requires RSC-R1UU-E8PR
Parts List
Part NumberQtyDescription
AOC-PG-i2+AOC-PG-i2+1Proprietary 2-port Gigabit Ethernet Controller
BracketMCP-240-00076-0N1Low-profile End Bracket with screws
Driver DiskCDR-NIC1Driver and Software CDROM

* Standard low-profile form factor is also available as bundled solutions with Supermicro servers and motherboards
