Carte Réseau Supermicro AOC-UTG-i2 Maximize

Carte Réseau Supermicro AOC-UTG-i2

UIO full-height Dual-Port 10Gb Ethernet card
• Interface: PCI-E x8
• Port: 2 CX4 ports
• Speed: 10 Gigabit/port
• Controller: Intel® 82598EB

Plus de détails

10GbE Server Adapter


Affordable High-performance & Energy-saving 10Gb Ethernet Solution

Supermicro Universal I/O 2-port 10-Gigabit Ethernet LAN card

AOC-UTG-i2 is a high-performance, dual-port 10Gb network controller optimized for multicore Intel® Xeon® processor-based servers and virtualized environments. This adapter addresses the networking bottlenecks associated with server consolidation and is ideal for virtualization and demanding enterprise applications such as storage and high-performance computing. This excellent energy-efficient UIO card is also an ideal choice to unify storage while maximizing performance with low TCO.

To order, contact your distributor. This product is only available through Supermicro.
Compliance
RoHS
RoHS 6/6
  • RoHS Compliant 6/6, Pb Free
Downloads
User's GuideDownload ] (502 KB)
DriverFTP Site ]
Driver CDFTP Site ]
DatasheetDownload ]
Compatible UIO Motherboards and Servers
Motherboards
All Supermicro UIO Motherboards
Servers
All Supermicro UIO Servers
Compatible Cable
Ethernet 10GBase-CX4 Copper Cable (Not Included)
Highlights
  • High-performing, PCI-E 10Gb Ethernet connection ideally suited for demanding enterprise applications
  • Dual-port, industry-leading, energy-efficient design
  • Introduces multiple product innovation optimized for virtualization and ideal for server consolidation
  • High-volume stable architecture that includes broad operating system support
  • Optimized for Supermicro UIO servers and motherboards
Key Features
  • Dual-port Intel® 82598EB with two CX4 connectors
  • PCI-E x8 Full-height half-length UIO form factor *
  • Intel® I/O Acceleration Technology (I/OAT) for improved CPU utilization
  • Low-latency interrupts
  • 16 Virtual Machine Device queues (VMDq) for virtualized environments
  • Direct Cache Access (DCA) to eliminate cache misses and reduce CPU load
  • Tx/Rx, IP, TCP, and UDP checksum offloading (IPv4, IPv6) capabilities to increase throughput and lower processor utilization
  • Preboot eXecution Environment (PXE) support
  • Jumbo Frames support up to 9.5KB packets
  • Intel® PROSet Utility for Windows® Device Manager to support network teaming
  • Simple Network Management Protocol (SNMP) and Remote Network Monitoring (RMON) statistic counters
  • Energy-efficient design (maximum 6.5W)
  • RoHS Compliant 6/6
  • Support CX4 Copper cable up to 15m
  • Operating temperature 0-55°C
  • Storage humidity: 90% non-condensing relative humidity at 35°C
  • OS Support: Windows®, Linux, VMWare
Parts List
Part NumberQtyDescription
AOC-UTG-i2AOC-UTG-i21UIO 2-port 10GbE Controller
BracketMCP-240-00050-0N1Full-height End Bracket with Screws
Driver DiskCDR-NIC1Driver and Software CDROM

* Standard low-profile form factor is also available as bundled solutions with Supermicro servers and motherboards
