Alimentation Zippy 1U B1U-6150F?150W? Maximize

Alimentation Zippy 1U B1U-6150F?150W?

Dimension?190.00x100.00x40.50  (mm)

/ 7.48x3.94x1.59  (inch)

Input?VOLTAGE: DC – 20 V ~ -- 28 V
INPUT CURRENT: 10.0 A ( RMS ) AT – 24 VDC
INRUSH CURRENT: 20A MAX

Plus de détails

VOLTAGE: DC – 20 V ~ -- 28 V
INPUT CURRENT: 10.0 A ( RMS ) AT – 24 VDC
INRUSH CURRENT: 20A MAX



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
5V218.00± 5%± 1%80mV



12V16± 8%± 1%120mV



-5V0.10.5±10%± 1%120mV



-12V0.11-10%~+10%± 1%150mV



3.3V110± 5%± 1%80mV



+5VSB0.11.5± 5%± 1%50mV









REMARKS: +5 V AND + 3.3 V TOTAL OUTPUT MAX. 100 WATTS

*12V Max. Current : 6A
*TEMPERATURE RANGE: OPERATING 0? ~ 50?
*EFFICIENCY: 65% TYPICAL AT DC–24 INPUT, FULL LOAD
* HUMIDITY:OPERATING:20%-95%, NON-OPERATING:10%-95%
* REMARKS:85% IS NORMAL CONDITION AND 95% IS WITH SPECIAL COATING PROCESS
*EMI NOISE FILTER: FCC CLASS A CISPR22 CLASS A
*SAFETY: UL, CSA, TUV
*Remote on/off control
*Cooling: ONE 40 mm DC FAN
*Input source connector : POSITRONIC BLUE CONNECTOR
*Serial ATA optional


*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
