Alimentation Zippy 1U P1S-5150V?150W? Maximize

Alimentation Zippy 1U P1S-5150V?150W?

Dimension?150.00x82.00x40.50  (mm)

/ 5.91x3.23x1.59  (inch)

Input?VOLTAGE? 90?264VAC FULL RANGE
FREQUENCY? 47?63HZ
INPUT CURRENT?2A (RMS) FOR 115 VAC
1A (RMS) FOR 230 VAC
INRUSH CURRENT?35A MAX. FOR 115 VAC
70A MAX. FOR 230 VAC

Plus de détails

VOLTAGE? 90?264VAC FULL RANGE
FREQUENCY? 47?63HZ
INPUT CURRENT?2A (RMS) FOR 115 VAC
1A (RMS) FOR 230 VAC
INRUSH CURRENT?35A MAX. FOR 115 VAC
70A MAX. FOR 230 VAC



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
+5V010.00±5%±50mV50mV



+12V0.18±5%±120mV120mV



-12V00.5±10%±120mV120mV



+3.3V012±5%±50mV50mV



+5VSB02±5%±50mV50mV











+5V AND +3.3V TOTAL OUTPUT MAX: 50W
+5V, +3.3V, +12V, -12V TOTAL OUTPUT MAX: 144W

* TEMPERATURE RANGE?OPERATING 0??50?
* HOLD UP TIME?16mS MINIMUM AT 115V FULL LOAD
* DIELECTRIC WITHSTAND?INPUT/OUTPUT 1800 VAC FOR 1 SECOND INPUT TO FRAME GROUND 1800 VAC FOR 1 SECOND
* EFFICIENCY?80%±2% TYPICAL?AT FULL LOAD 115Vac
* POWER GOOD SIGNAL?ON DELAY 100mS TO 550mS?OFF DELAY 1mS
* OVER POWER PROTECTION?110?170% MAX
* OVER VOLTAGE PROTECTION: +3.3V?3.6~4.3V, +5V?5.6~6.5V, +12V?13.2~15V
* SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V, AUTO-RECOVERED: +5VSB
* SAFETY : TO MEET UL, CUL, TUV, CCC
* REMOTE ON/OFF CONTROL
THE POWER SUPPLY SHALL ACCEPT A LOGIC OPEN COLLECTOR LEVEL WHICH WILL DISABLE/ENABLE ALL THE OUTPUT VOLTAGE (EXCLUDE +5V STAND BY).
AS LOGIC LEVEL IS LOW?OUTPUTS VOLTAGE WERE ENABLE? AS LOGIC LEVEL IS HIGH?OUTPUTS VOLTAGE WERE DISABLE.
* MEET IEC-1000-3-2 CLASS D


*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
