Alimentation Zippy 1U H1W-5AD0V?1400W? Maximize

Alimentation Zippy 1U H1W-5AD0V?1400W?

Dimension?295.00x100.00x40.00  (mm)

/ 11.61x3.94x1.57  (inch)

Input?VOLTAGE: 115 - 240 VAC FULL RANGE
FREQUENCY: 47 - 63 Hz
INPUT CURRENT: 15/10 AMPS MAXIMUM AT ANY

Plus de détails

VOLTAGE: 115 - 240 VAC FULL RANGE
FREQUENCY: 47 - 63 Hz
INPUT CURRENT: 15/10 AMPS MAXIMUM AT ANY
LOW/HIGH RANGE INPUT VOLTAGE
INRUSH CURRENT: 15/30 AMPS @ 110/220VAC
POWER FACTOR CORRECTION: PFC CAN REACH THE TARGET OF
95% @ 115V, FULL LOAD, FOLLOWING THE STANDARD OF IEC 61000-3-2



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
+5V135.00± 5%± 1%50mV



+12V2116± 5%± 1%120mV



-12V00.5± 5%± 1%120mV



+3.3V131± 5%± 1%50mV



+5VSB0.14± 5%± 1%50mV











* TOTAL OUTPUT POWER OF +5V AND +3.3V NOT EXCEED 210W.
* TOTAL OUTPUT POWER NOT EXCEED 1400W for 180~264VAC.
* TOTAL OUTPUT POWER NOT EXCEED 1200W for 103~132VAC.

* TEMPERATURE RANGE: OPERATING 0? ~ 50?, STORAGE –20?~80?
* EFFICIENCY: 90% TYPICAL @ 230V FULL LOAD
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
* HOLD UP TIME: 17mS MINIMUM AT FULL LOAD & NOMINAL INPUT VOLTAGE
* OUTPUT PROTECTION: OPP / OVP / SCP
* 3.3V/5V REMOTE SENSING

*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
