Alimentation Zippy 1U R1S2-5380V4H?380W? Maximize

Alimentation Zippy 1U R1S2-5380V4H?380W?

Dimension?230.00x176.00x41.80  (mm)

/ 9.06x6.93x1.65  (inch)

Input?VOLTAGE? 90?264VAC FULL RANGE
FREQUENCY? 47?63HZ
INPUT CURRENT?5.5A (RMS) FOR 115 VAC
2.5A (RMS) FOR 230 VAC
INRUSH CURRENT?60A MAX. FOR 115 VAC PER MODULE
80A MAX. FOR 230 VAC PER MODULE

Plus de détails

VOLTAGE? 90?264VAC FULL RANGE
FREQUENCY? 47?63HZ
INPUT CURRENT?5.5A (RMS) FOR 115 VAC
2.5A (RMS) FOR 230 VAC
INRUSH CURRENT?60A MAX. FOR 115 VAC PER MODULE
80A MAX. FOR 230 VAC PER MODULE



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
+5V0.520.00±5%±1%50mV



+12V2.030±5%±1%120mV



-12V0.10.5±10%±1%120mV



+3.3V0.520±5%±1%50mV



+5VSB0.12.5±5%±1%50mV











WHEN CONDITIONS OF BOTH +5V/0A +3.3V/0A, MIN LOAD OF 4A AT +12V IS A MUST

* TEMPERATURE RANGE?OPERATING 0??40?, STORAGE -20?~80?
* HOLD UP TIME?WHEN POWER SHUTDOWN DC OUTPUT 5V MUST BE MAINTAIN 16MSEC IN REGULATION LIMIT AT NORMAL INPUT VOLTAGE
* EFFICIENCY?84% TYPICAL?AT FULL LOAD 115VAC
* LEAKAGE CURRENT: 3.5 MA. MAX. AT NOMINAL VOLTAGE 250VAC
* POWER GOOD SIGNAL?ON DELAY 100mS TO 550mS?OFF DELAY 1Ms
* OVER POWER PROTECTION?110?160% MAX
* OVER VOLTAGE PROTECTION: +5V?5.6~6.7V, +3.3V?3.6~4.3V, +12V?13~15V
* SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V, +5VSB
* SAFETY: MEET UL60950, TUV EN-60950, CB IEC 60950
* WARNING METHOD: AUDIO ALARM(BUZZER SOUND, RESETABLE), FALUT LED, TTL


*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
