Alimentation Zippy 1U R1M-6251P?250W? Maximize

Alimentation Zippy 1U R1M-6251P?250W?

Dimension?260.00x180.00x40.60  (mm)

/ 10.23x7.08x1.59  (inch)

Input?VOLTAGE: 90 ~ 264 VAC FULL RANGE
FREQUENCY : 47 ~ 63 Hz
INPUT CURRENT: 6.0 / 3.0 A FOR 115 / 230 VAC
INRUSH CURRENT: 60A / 90A MAX. FOR 115 / 230
VAC PER POWER MODULE

Plus de détails

VOLTAGE: 90 ~ 264 VAC FULL RANGE
FREQUENCY : 47 ~ 63 Hz
INPUT CURRENT: 6.0 / 3.0 A FOR 115 / 230 VAC
INRUSH CURRENT: 60A / 90A MAX. FOR 115 / 230
VAC PER POWER MODULE



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
+5V325.00± 5%± 1%50mV
+12V216± 7%± 1%100mV
-5V0.050.5±10%± 1%120mV
-12V0.050.5±10%± 1%150mV
3.3V115± 5%± 1%50mV
+5VSB0.12± 5%± 1%50mV
REMARKS: *TOTAL CURRENT OF +5V AND + 3.3V NOT EXCEED 28 A *TOTAL +5V AND 3.3V AND 12V POWER NOT EXCEED 232 W

* TEMPERATURE RANGE: OPERATING 0? --- 50?, STORAGE –20? --- 80?
* HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & 90 VAC INPUT VOLTAGEv * EFFICIENCY: 65% TYPICAL, AT FULL LOAD
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
* OVER POWER PROTECTION
* OVER VOLTAGE PROTECTION
* OVER CURRENT PROTECTION
* SHORT CIRCUIT PROTECTION
* EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
* SAFETY: MEET UL, CSA 60950, TÜV EN-60950
* FAULTY ALARM METHODS : LED, BUZZER, TTL SIGNAL
* HOT-SWAPPABLE / HOT-PLUGGABLE 1 + 1 REDUNDANCY FUNCTION
* BALANCE LOAD SHARING DESIGN
* REMOTE SENSING DESIGN
* ISOLATION: BUILT-IN IN THE POWER MODULE
* MEET IEC-1000-3-2 CLASS D ( ACTIVE PFC )
* COOLING: TWO 40 mm DC FANS

*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
