Alimentation Zippy 1 U RP1U-5240V?240W? Maximize

Alimentation Zippy 1 U RP1U-5240V?240W?

Dimension?270.00x100.00x40.50  (mm)

/ 10.63x3.94x1.57  (inch)

Input?VOLTAGE:  90 ~ 264 VAC FULL RANGE
FREQUENCY : 47 ~ 63 HZ

Plus de détails

VOLTAGE:  90 ~ 264 VAC FULL RANGE
FREQUENCY : 47 ~ 63 HZ
INPUT CURRENT: 4.0A(RMS) FOR 110VAC; 2.0A(RMS) FOR 220VAC
INRUSH CURRENT: 35A MAX. FOR 110 VAC; 70A MAX. FOR 220 VAC



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
+5V020.00±5%±1%50mV



+12V0.120±5%±1%120mV



-12V00.3±5%±1%120mV



+3.3V020±5%±1%50mV



+5VSB0.12.5±5%±1%50mV











1. THE OUTPUT POWER OF +5V & +3.3V NOT EXCEED 150 WATTS
2. +5V, +3.3V AND +12V, -12V TOTAL OUTPUT MAX.: 230W
3. TOTAL POWER: 240W

* TEMPERATURE RANGE: OPERATING 0? --- 50?, STORAGE –20?~80?
* HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE
& EFFICIENCY: 78%±2 TYPICAL AT 230V, FULL LOAD; EFFICIENCY CALCULATION: WHEN CALCULATING OUTPUT POWER, INTERNAL FAN CURRENT SHALL BE INCLUDED WITH 12V OUTPUT.
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
* OVER POWER PROTECTION: 110~170%
* OVER VOLTAGE PROTECTION: +3.3V?3.6~4.3V, +5V?5.6~6.5V, +12V?13.2~15V
* SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V, +5VSB
* EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
* LEAKAGE CURRENT: 3.5MA MAX. AT NOMINAL VOLTAGE 264VAC
* SAFETY: MEET UL 60950-1, CSA 22.2 NO 60950-1, TUV IEC 60950-1, CCC
* MEET IEC-1000-3-2 CLASS D


*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS
