Alimentation Zippy 1U DR1M-6221F?220W? Maximize

Alimentation Zippy 1U DR1M-6221F?220W?

Dimension?260.00x180.00x40.50  (mm)

/ 102.36x70.87x15.94  (inch)

Input?VOLTAGE:  DC -36 V~ -72 V
INPUT CURRENT: 7.0 A ( RMS ) FOR -48VDC
INRUSH CURRENT: LESS THAN 10A FOR EACH MODULE

Plus de détails

VOLTAGE:  DC -36 V~ -72 V
INPUT CURRENT: 7.0 A ( RMS ) FOR -48VDC
INRUSH CURRENT: LESS THAN 10A FOR EACH MODULE



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
5V3.025.00± 5%± 50mV50mV



12V2.016± 5%± 50mV120mV



-5V00.5± 10%± 50mV150mV



-12V00.5± 10%± 50mV150mV



3.3V1.015± 5%± 50mV50mV



+5VSB0.12± 5%± 50mV50mV









REMARKS:
THE OUTPUT POWER OF 5V & 3.3V MAX: 28A

* TEMPERATURE RANGE: OPERATING: -10? --- 40?
* HUMIDITY:OPERATING:20%-80%, NON-OPERATING:10%-90%
* REMARKS:80% IS NORMAL CONDITION AND 90% IS WITH SPECIAL COATING PROCESS
* STORAGE: -20? --- 80?
* HOLD UP TIME: 1.6 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE
* DIELECTRIC WITHSTAND: INPUT / OUTPUT 1500 VAC FOR 1 SECOND
INPUT TO FRAME GROUND 1500 VAC FOR 1 SECOND
* EFFICIENCY: 68% TYPICAL AT -48VDC FULL LOAD
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
* OVER POWER PROTECTION: 110% ~ 160%
OVER VOLTAGE PROTECTION: +5V ? 5.7V ~ 6.6V, 3.3V ? 3.9V ~ 4.8V +12V ? 13.0V ~ 15.0V
* SHORT CIRCUIT PROTECTION: +5V, +12V, +3.3V, +5VSB, -5V, -12V
* EMI NOISE FILTER: FCC CLASS A, CISPR22 CLASS A
* SAFETY: UL 60950, TÜV EN-60950, CB IEC 60950, CCC GB4943-1995, GB9254-1998, GB17625.1-1998
* REMOTE ON / OFF CONTROL
THE UNIT SHALL ACCEPT A LOGIC OPEN COLLECTOR LEVEL WHICH WILL DISABLE / ENABLE ALL THE OUTPUT VOLTAGE (EXCLUDE +5V STANDBY), AS LOGIC LEVEL IS LOW, OUTPUTS VOLTAGE WERE ENABLE, AS LOGIC LEVEL IS HIGH, OUTPUTS VOLTAGE WERE DISABLE.
* 3.3V / 5V REMOTE SENSING
* COOLING: ONE 40mm DC FAN
* CONNECTOR POWER INPUT
A. POSITRONIC: PLB06M CONNECTOR
B. TERMINAL BLOCK


*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS
