Alimentation Zippy 1 U M1K2-5C00V4H?1200W? Maximize

Alimentation Zippy 1 U M1K2-5C00V4H?1200W?

Dimension?400.00x106.00x41.30  (mm)

/ 15.75x4.17x1.63  (inch)

VOLTAGE? 90?264VAC FULL RANGE
FREQUENCY? 47?63HZ
INPUT CURRENT?7.5A ?RMS?FOR 230VAC
15A?RMS?FOR 115VAC
INRUSH CURRENT?15A MAX. FOR 115 VAC PER MODULE
30A MAX. FOR 230 VAC PER MODULE

Plus de détails

VOLTAGE? 90?264VAC FULL RANGE
FREQUENCY? 47?63HZ
INPUT CURRENT?7.5A ?RMS?FOR 230VAC
15A?RMS?FOR 115VAC
INRUSH CURRENT?15A MAX. FOR 115 VAC PER MODULE
30A MAX. FOR 230 VAC PER MODULE



Output VoltageOutput Current Min.Output Current Max.Output Current PeakRegulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]
+5V022.00±5%±1%50mV



+12V2100±5%±1%120mV



-12V00.5±5%±1%120mV



+3.3V022±5%±1%50mV



+5VSB0.13±5%±1%50mV



















POWER MODULE TOTAL OUTPUT POWER OF +5V AND +3.3V NOT EXCEED 150W
POWER MODULE TOTAL OUTPUT POWER NOT EXCEED 1200W

* TEMPERATURE RANGE?OPERATING 0??50??STORAGE -20??80?
* HOLD UP TIME?10mS MIN. AT FULL LOAD & 115 VAC INPUT VOLTAGE
* DIELECTRIC WITHSTAND?INPUT/OUTPUT 1500 VAC FOR 1 minute INPUT TO FRAME GROUND 1500 VAC FOR 1 minute
* EFFICIENCY?TYPICAL 83% AT 115V, 12V/83A 5VSB/0.1A; TYPICAL 86% AT 230V, 12V/83A 5VSB/0.1A
* POWER GOOD SIGNAL?ON DELAY 100mS TO 500mS?OFF DELAY 1mS
* OVER POWER PROTECTION?110?150% MAX
* OVER VOLTAGE PROTECTION?+3.3V?3.7~4.1V, +5V?5.7~6.5V, +12V?12.8~13.9V
* SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V
* SAFETY?TO MEET UL, CUL, TUV
* FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL
* MEET IEC-1000-3-2 CLASS D (ACTIVE PFC)


*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
